Operating room series
Double open automatic doorsdoor operator
Controller in accordance with medical electrical safety requirements, the motor using Japan's top spiral bevel gear technology, mute, Energy saving, high efficiency, long life
Unique combination of high strength T6 aluminum alloy support beam
Special track and pulley block design, to ensure ultra-quiet operation
White dust-proof timing belt for improved clean performance
Optional foot sensor or feel should be open
Integration of the track, the chassis cover, the direct wall surface mounting, installation is simple and quick, but also can be embedded, And the wall for the same plane, giving the overall sense
Can be integrated into the wisdom of hospital access control management system
door features
The door body is composed of a special aluminum frame structure and a door panel
Door around the installation of non-toxic silicone seal to meet the clean requirements
The door liner is made of aluminum honeycomb / polyurethane foam, strong, thick, flat, to ensure good air tightness and sound insulation.
Door can be used galvanized steel / aluminum / large flat stainless steel plate
Two - layer plane fillet observation window
Optional embedded handle / round tube handle
Door can be stainless steel or aluminum cladding, the middle rubber bump with convex, closed also completely in a good sealed state
parameter
- Open the foot sensor / hand sensor
- Security-assisted infrared anti-clip security light
- Door weight ≤ 150kg
- Open the door speed 250 ~ 550mm / s (adjustable)
- Closed door speed 250 ~ 550mm / s (adjustable)
- Opening time 0 ~ 20s (adjustable)
- Closing force F> 70N
- Manual thrust <80N
- Power consumption of the whole machine <120W
