Anti-radiation series
Heavy - duty radiation automatic doorsdoor operator
All imports of H-8 / H-18 super-heavy automatic doors system, using a wide white dust-proof synchronous belt, load 500KG to On the use of all imported H-18 super-heavy automatic door system, high-strength stainless steel track, chain belt, planetary gears, Load capacity of up to 1000KG
Special high strength T6 aluminum alloy support beam
Special heavy-duty load hanger and components and large radius of high-strength wear-resistant sliding wheel to ensure smooth and quiet operation
Optional foot sensor or feel should be open
Can be plug-in or embedded installation
Equipped with hubs can be integrated into the wisdom of the hospital channel centralized control management system
door features
The door body is composed of a special aluminum frame structure and a door panel
Door and frame-lined lead plate, lead equivalent of 4-6mmPa, can shield X-ray, to prevent a variety of harmful radiation leaks Damage to human body, in line with diagnostic X-ray protection requirements
Doors installed non-toxic silicone seal, to meet the clean requirements
The door liner is made of aluminum honeycomb / polyurethane foam, strong, thick, flat, to ensure good air tightness and sound insulation.
Door can be used galvanized steel / aluminum / large flat stainless steel plate
parameter
- Door weight 500kg ~ 1000kg
- Open the door speed 450mm / s (adjustable)
- Closed door speed 450mm / s (adjustable)
- Opening time 0 ~ 20s (adjustable)
- Closing force F> 500N
- Manual thrust <150N
- Power consumption of the whole machine <120W
